Stingray 215LR
Stingray 215LR: Two-foot “itis”
Two-foot “itis” is normally a reference for moving up in size from a smaller boat to a larger one. It is the longing for a little bigger boat, a few more amenities, a little more room or just a little more performance.
In the case of Stingray’s new 215LR, the term could not be more relevant but, the funny thing is….the 215LR is actually a two-foot “step down” from its mother ship, the 235LR. A step down that surprisingly, does not sacrifice features or compromise performance. And, since the two-foot difference is strategically eliminated from various non-critical design points throughout the boat, not just from one area, there is little sacrifice to usable space.
-
- 5-Year Hull Protection Plan
- 3-Year Hull Blister Protection Plan
- Z-plane Hull, Patent # 5,063,868
- Certifications: NMMA, USCG, IMCI, EC
- MACT Compliant Resins & Gelcoats
- Floor Storage w/ Oversize Door
- High Output Bilge Blower
- Performance Notched Transom
- Insulated Ice/Storage Box with Drain
Hull
- Bow Storage
- Bow Anchor Storage
- Stainless Steel Stern, Bow & Spring Line Cleats
- Stainless Steel Pop-Up Cleats
- Stainless Steel Multi-Step Boarding Ladder
- Enclosed Head w/ Vent Window & Lighting
- Twin Sport Bucket w/ Bolster
Deck
- All Weather Marine Carpet – 20 oz.
- Backlit Instrumentation and Switches
- Integrated Electric Horn
- Deluxe Throttle and Trim Control
- Prem. 36oz. Foam Backed Vinyl w/ PreFix
- Oversized Cup Holders
- Helm Seats w/ Fore & Aft Adjustments
- Steel Burl Trim Package
- Self Bailing Fibreglass Floor Liner
- Fresh Water Sink
- MB Quart High Power CD Player (Upgrade)
- Fibreglass Cockpit Floor Liner
Cockpit
- Power Steering engine driven
- Easy Access Fuel Pump & Filter (service)
- Easy Access Water Pump (service)
- Fresh Water Flushing Attachment
- Full Up Drive Trim
- Cone Clutch Shifting Technology
- Drive unit with High Water Intakes
- High Flow Exhaust
Engine
*with Volvo Penta Engine Option
Standard Features
-
Hull
ID Product Price #50 Auto/Man 1 in Bilge Pump (1100 GPH) Std #51 Two-Tone Hull Color Stripe $632 #56 Electric Trim Tabs with LED indicator $1360 #68 Hydraulic Trim Tabs w/ LED Indicator $1270 Deck
ID Product Price #4 Full Canvas Set (Acrylic) $1381 #13 Cockpit Cover (Acrylic) w/ Support Pole $913 #14 Walk-thru Flap $137 #15 Camper Canvas (2 Tops, 4 Sides, and Aft $1690 #16 Side Curtains (For Top Enclosure) $350 #17 Cockpit and Bow Cover (Acrylic) w/ Poles $1308 #18 Bow Cover (Acrylic) w/ Support Pole $397 #55 Stainless Steel Hardware Package $594 #59 Pressurized Bow Shower Std #65 Bimini Top (Acrylic) Stand Up w/ Boot Std #66 Optional Black Canvas $190 #69 Pressurized Water w/ Transom Shower Std #661 Wakeboard Tower, Custom $3700 #900 Wakeboard Package 1 $4780 #901 Wakeboard Package 2 $4780 Cockpit
ID Product Price #21 MB Quart Transom Mounted LCD remote $241 #33 Snap-in Carpet-Std Seating $650 #39 Tilt Steering w/ Locking Detent Std #46 Fibreglass Cockpit Floor Liner Std #47 Filler Cushion Aft Walk Thru $450 #48 Digital Depth Finder w/ Depth Alarm $456 #49 Magnetic Compass (for navigation) Std #73 Cockpit Cover for Wake Tower $972 #75 Stereo, LCD Remotes, Bow and Transom $420 #76 Cockpit Table w/ Bow & Cockpit mounts Std #82 Twin Sport Bucket w/ Bolster Std #83 Adjustable Pedestal for 2 Bucket Seats $220 #84 Filler Cushion for Bow/Cabin $371 Engine
ID Product Price #19 Automatic Fire Extinguishing System $874 #30 Dual Battery System w/ VSR Switch $356 #36 Battery On/Off Switch w/ Safety Switch $137 #40 Transom Mounted Tilt Switch Std
Optional Features
Specifications
| Specifications | Imperial | Metric |
|---|---|---|
| Length Overall | 21' 11" | 6.7 m |
| Beam | 101 in | 257 cm |
| Bridge Clearance | 58 in | 147 cm |
| Average Dry Weight* (w/ popular engine) | 3705 lb | 5.0L engine |
| Fuel Capacity | 47 gal | 178 liter |
| Ice Box Capacity | 25+17 qt | 24+16 liter |
| Max Capacity | 11 people (2167lbs) | 11 people (983kg) |
| Free Board | 31 in | 79 cm |
| Molded Depth (Windshield Base to Keel) | 58 in | 147 cm |
| Max Depth (Including Windshield) | 72 in | 183 cm |
| Max Draft (Drive Down) | 34 in | 86 cm |
| Max Draft | 17 in | 43 cm |
| Bow Depth (Bow to Cushion Top | 17 in | 43 cm |
| Bow Depth (Max Depth) | 33 in | 84 cm |
| Bow Length (Max Length) | 59 in | 150 cm |
| Cockpit Depth (At Helm) | 34 in | 86 cm |
| Cockpit Width (Max Molded) | 81 in | 206 cm |
| Cockpit Length (Max Molded) | 107 in | 272 cm |
| Transom Angle | 15 | |
| Deadrise Angle | 19 |
*with Volvo Penta Engine Option
